Performance
Effective build volume (L x W x H)
Printing speed
Scan speed
Dimensional accuracy
Minimum feature size
Layer thickness
Technical Specifications
125 x 125 x 125 mm
Up to 200 cm³/h
Up to 500 mm/s
± 0.02 mm
50 µm
0.02 – 0.20 mm
Machine dimensions (L x W x H)
Shipping size (L x W x H)
Operation area
Machine weight
Footprint
Material
Air Purification
Laser
Supported materials (including but not limited to)
0.91 m x 0.91 m x 0.96 m
1.3 m x 1.3 m x 1.3 m
1.5 m x 1.5 m x 1.5 m
350 kg
SS304/316L, Cu, CuZn, Al6061, Al1013, Ti-6Al-4V, NiTi, Fe, Ti and more.
Pre-filter grade
HEPA filter grade
G3
H12
Class
1
Metal foil roll size
150 mm width，Φ280 mm，6 kg
Power
Consumption
1 kW max.
Requirements
Single phase 100V - 130V 10A max. or 220V - 240V 5A max. 50/60 Hz
